Pipes For Nitric Acid & Sulfuric Acid

What are Pipes For Nitric Acid & Sulfuric Acid

Pipes for nitric acid and sulfuric acid are metal alloy conduits engineered to leverage passive surface oxide films to block acid corrosion.However,they are highly grade-sensitive,meaning the wrong pairing of a specific stainless steel grade with a certain acid concentration will trigger a sudden,catastrophic pipeline rupture.

Core Strengths of Pipes For Nitric Acid & Sulfuric Acid

Core Strengths in Nitric Acid Pipeline Service

Forms a highly stable,self-healing chromium-oxide passive film on the inner wall immediately upon contact with commercial nitric acid,completely blocking acid penetration.

Employs ultra-low carbon chemistry to eliminate chromium carbide precipitation during welding,preventing catastrophic cracking at joint boundaries.

Utilizes high-chromium or silicon-engineered matrices to sustain negligible metal-loss rates under highly oxidizing,boiling,and condensing nitric acid environments.

Prevents chemical leaching,trace metal contamination,or fluid discoloration,making it ideal for the transport of electronic-grade and pharmaceutical-grade pure nitric acid.

Core Strengths in Sulfuric Acid Pipeline Service

Deploys high-alloy formulations enriched with nickel,molybdenum,and copper to survive aggressive mid-range concentrations where standard steels fail.

Leverages silicon-alloyed stainless variants to form a rugged,erosion-resistant silicon barrier against high-velocity 93% to 99% hot concentrated sulfuric acid.

Offers an economical operational lifespan in highly dilute sulfuric solutions using standard 316L,bypassing the extreme cost of titanium or Hastelloy.

Retains superior mechanical stiffness and profile stability when subjected to intense localized heat generation caused by accidental water dilution or moisture entry.

Universal Advantages Across Both Acid Systems

Eliminates risks of vacuum collapse,gas permeation,or thermal delamination that frequently plague plastic-lined composite piping configurations.

Supports standard high-integrity industrial welding (TIG/MIG) to establish fully sealed,zero-leak,monolithic pipe networks that maximize facility safety.

Provides high impact resistance against external mechanical trauma and features a melting point above 1300℃ to act as a critical containment barrier during plant fires.

Features a high modulus of elasticity that prevents structural sagging,requiring far fewer pipe rack hangers or support anchors compared to thermoplastics.

Common Standards of Pipes For Nitric Acid & Sulfuric Acid

Critical Standards	Description/Usage
ASTM A312	Standard specification for seamless,straight-seam welded,and heavily cold-worked austenitic stainless steel pipes intended for high-temperature and general corrosive services.
ASTM A790	Standard specification covering seamless and welded ferritic/austenitic (duplex) stainless steel pipes optimized for higher mechanical strength and balanced corrosion resistance.
ASTM A269	Covers nominal-wall-thickness,seamless,and welded austenitic steel tubing for general corrosion-resisting and low- or high-temperature lines.
ASME B36.19M	Standard dimension specification establishing the size,schedules,and structural wall thicknesses for stainless steel piping systems.

Nitric Acid Service Standards

UNS S30600 / UNS S32615
310L NAG / UNS S31002
304L NAG (Nitric Acid Grade)
304L (UNS S30403 / ASTM A312)

Sulfuric Acid Service Standards

Alloy 20 (UNS N08020)
Duplex 2205 (UNS S32205 / ASTM A790)
904L (UNS N08904 / ASTM A312)
316L (UNS S31603 / ASTM A312)

Stainless Tubings Supplier in china

Hastelloy Pipe
Inconel Pipe
Monel Pipe

Incoloy Pipe
Nickel Pipe
Duplex Pipe

Get Started

What are pipes for concentrated nitric acid and concentrated sulfuric acid

Compared to pipes for nitric and sulfuric acids,stainless steel pipes for concentrated nitric and sulfuric acids represent a highly specialized,high-alloy piping system specifically designed to withstand highly corrosive,over-passivating,or oxidizing chemical environments in which standard stainless steel fails.

Core Strengths of pipes for concentrated nitric acid & sulfuric acid

High silicon levels generate a dense,self-healing silicon dioxide surface film that remains completely inert where traditional chromium-oxide films dissolve.

They eliminate intergranular corrosion in fuming 98% nitric acid circuits,resisting the transpassive acceleration that destroys standard 304L or 316L steels.

They resist velocity-sensitive erosion-corrosion in hot 93% – 99% sulfuric acid.This allows safe design velocities above 2.5m/s compared to the ＜ 0.8m/s limits of carbon steel.

Unlike thermoplastic (PVDF/CPVC) or glass linings,these alloys maintain high structural integrity and pressure ratings across elevated process temperatures up to 120℃.

Exceptional passive stability prevents iron ions from leaching into the process stream,protecting the high purity of the chemical product.

Common Standards of pipes for concentrated nitric acid & sulfuric acid

Critical Standards	Description/Usage
ASME SA312 / ASTM A312	Core manufacturing specification covering seamless and straight-seam welded high-silicon austenitic pipes.
ASTM A262	Standard practices for detecting susceptibility to intergranular attack,critically deployed via Practice C (Huey Test) to certify concentrated nitric acid grades.
ASTM A342	Standard test methods for permeability of feebly magnetic materials,ensuring the fully austenitic phase structure required for acid resistance.
Project Technical Agreement	Mandatory supplementary standard defining specialized low-heat weld procedures,matching high-silicon fillers,and mandatory post-weld solution annealing.

Main Application Specifications and Materials

Category	Grades	Standards	Size Range
Concentrated Nitric Acid Service	00Cr14Ni14Si4 (C4), KY704	ASME SA312	Outside Diameter (OD): Φ6 – Φ325
Concentrated Sulfuric Acid Service	UNS S32615, UNS S38815	ASME SA312	Outside Diameter (OD): Φ6 – Φ325
